The ultimate way to experience Lambertones.

Below are specs and explanations of the different wiring harness variations available based on the SSS, HSS, or HSH configuration chosen.

S5W Details:

1 Volume, 2 Tone

3 - 920D Custom 450G Series 250K Pots by CTS

1 - Genuine CRL USA 5-Way Switch

1 - .022 Orange Drop Capacitor by Sprague Electric

1 - Pure Tone Output Jack

920D Custom Signature Wiring by Gavit Wire

Made in USA

S5W-50 Details:

This wiring scheme provides a tight, transparent tone with that classic quack. Unlike more modern wiring schemes, it features a reduced treble cut when rolling back the volume control. The highs seem to be clearer, especially with the volume pot rolled back. This harness effectively gives you a treble bleed kit function without adding the extra cap and resistor.

S7W Details:

The 920D Custom S7W 7-Way Wiring Harness will rock your world. This wiring harness allows 2 additional pickup configurations for your standard S style guitar. The push/pull pot turns on the neck pickup allowing you to have the bridge and neck on and all 3 pickups on together. These 2 added pickup combinations, along with our top notch wiring, will make your tone stand out.

S5W-HSSL:

The 920D Lambertones Custom S5W-HSSL harness is designed for guitars with a full sized humbucker in the bridge position. It features a standard Oaks 5-way switch and allows the single coil pickups to "see" 250K volume control while the humbucker "sees" 500K volume control. This has a push/pull 2nd tone knob that not only only affects the Bridge humbucker tone but also allows you to split-coil the bridge humbucker on command for a single coil vibe in position 1 or an authentic SSS style position 2 tones.

S5W-HSS:

The 920D Custom S5W-HSS harness is designed for guitars with a full sized humbucker in the bridge position. It features a 5-way super switch that automatically splits the humbucker when combined with the middle pickup (position 2). It also allows the single coil pickups to "see" 250K volume control while the humbucker "sees" 500K volume control.

HSH-L:

Custom Lambertones wiring harness featuring CTS pots, Orange Drop caps, Oaks 5-way switch, independent tone controls for neck and bridge humbuckers with a push/pull 2nd tone splitting both humbuckers on command.
